Vacuum Oven XFE020

Price: Call

Products code: XFE020

Trademark:France Etuves

Warranty:

Our vacuum oven XFE020 is suitable for gentle drying of sensitive products, thermal treatments of oxidizable materials, quick drying of powders and granulate… in pharmaceutical, cosmetics, plastics, electronics, chemical, agrifood… laboratories or industries.

Tags: Vacuum drying cabinet Etuves Oven

Vacuum ovens
Model: XFE020
Performances
Maximum temperature : 200 °C (300°C as option)
Minimum temperature : Ambient temperature + 20°C
Temperature fluctuation : < ± 0.2 °C
Vacuum control accuracy : ⩽ 2 mbar (according to your vacuum pump)
Vacuum data
Vacuum range : up to -1000 mbar (relative pressure) or 1 mbar (absolute pressure)
Sensor : Piezo
Vacuum measurement range : 0 to -1000 mbar
Sizes*
Working volume : 20 liters
Internal sizes (W x D x H) : 250 x 320 x 250 mm
External sizes (W x D x H) : 510 x 575 x 610 mm
Thickness of the glass window : 10 mm
* Some options may change the sizes of the oven
Trays made of aluminium
Number : 1 delivered / 4 maximum inside the oven
Tray sizes : 224 x 280 mm
Working tray sizes : 216 x 280 mm
Maximum load per tray : 30 kg
Maximum load in the oven : 60 kg (trays weight not included)
Electrical data & others
Power : 230V ~1P 50Hz 16A
Heating power : 800 W
Total installed power with vacuum pump : 1950 W
Door number : 1
Weight : 60 kg
Standard vacuum pump model recommended : DVP RC4D

Vacuum ovens
Model: XFP020
Performances
Maximum temperature : 200 °C (300°C as option)
Minimum temperature : Ambient temperature + 20°C
Temperature fluctuation : < ± 0.2 °C
Vacuum control accuracy : ⩽ 2 mbar (according to your vacuum pump)
Vacuum data
Vacuum range : up to -1000 mbar (relative pressure) or 1 mbar (absolute pressure)
Sensor : Piezo
Vacuum measurement range : 0 to -1000 mbar
Sizes*
Working volume : 20 liters
Internal sizes (W x D x H) : 250 x 320 x 250 mm
External sizes (W x D x H) : 510 x 575 x 610 mm
Thickness of the glass window : 10 mm
* Some options may change the sizes of the oven
Trays made of aluminium
Number : 1 delivered / 4 maximum inside the oven
Tray sizes : 224 x 280 mm
Working tray sizes : 216 x 280 mm
Maximum load per tray : 30 kg
Maximum load in the oven : 60 kg (trays weight not included)
Electrical data & others
Power : 230V ~1P 50Hz 16A
Heating power : 800 W
Total installed power with vacuum pump : 1950 W
Door number : 1
Weight : 60 kg
Standard vacuum pump model recommended : DVP RC4D
